28” Single Row Curved 140w

$505.40 CAD

Our single row light bar line offers a sleek and slim line design. When you need light and want to keep it low profile, single row is the way to go!

In stock


Our 28″ single row curved 140w light bar offers a sleek, low profile design. This light throws 11,200 lumens from the top of the line CREE LED chips! The single row line comes in either curved or straight design. The curved design gives a wider spread of light with the beam angle of 120° spread of light. Some people think that the single row light bars are less bright than the double row. This is not the case. The single row bars use 5-watt LED chips and also have a projector optic on each chip that gives a 15 to 20% boost of light adding 1 watt per inch. This means that the single row light bar is giving the light of 6 watts per inch, which is equal to the double row light bar.

The single row bars are popular for tighter spaces and those who wish to have a low-profile design that is also functional. Made from military grade cast aluminum housing with a nearly indestructible poly-carbonate Lexan composite lens. Yes, we tested it! We shot at our light bar with a shotgun, at ten paces away and the lens deflected the blast, leaving only small dimples in the lens. We are confident that our products will stand up to the test of time and that is why we back them with a 5-year full product free replacement warranty.

Get the light you need with our 28″ single row curved 140w light bar.

For quick and simple install, add on a Plug and Play DT-1 Harness (single output). Or if mounting two lights up to 180 watts combined you can run the Plug and Play DT-2 Harness (Dual Output) to run two lights at once!

  • LED Power: 140w
  • Lumens: 11,200 Lms
  • Dimensions: 28″ lens, 29″ bar face and measures 30″ from end to end. Please see photo attached for dimensions
  • Beam Angle: 120° spread of light
  • Operating Voltage: 10-30 V D/C
  • Waterproof Rating: IP 68 for more info, follow this link http://www.dsmt.com/resources/ip-rating-chart/
  • Housing Color: Black
  • Interior: Chrome Reflectors
  • Lens: Poly-carbonate/Lexan Composite
  • Cast Aluminum Housing
  • Military Grade Aluminum
  • 50,000+ Hours LED Life
  • Military Vent/Breather
  • 5 Year Full Free Product Replacement Warranty

Check the FINE PRINT of competitors “lifetime” warranty and you will see that it is NOT  “lifetime free replacement”.
Usually a short period of time for the “free replacement”.
Once the free term is up, it will be service & repair with down time


Additional information

Weight 2.63 kg
Dimensions 85.73 × 14.605 × 9.525 cm
